Mimic Controller - obsolete

The Mimic Controller provides a convenient and cost effective solution to any system that requires supplementary graphical indication of the installation via LED technology.

These units, unlike a panel mounted LED array, which to be meaningful must also have a printed lookup table or picture adjacent to the panel, provide an unambiguous graphical representation of the actual zones in fire.

The unit can be mounted either internally in an MxPro 5 multi-loop control panel, or alternatively, in a bespoke remote enclosure. Each unit comprises a graphical representation of the installation together with a programmable mimic driver card and LED indicators. The mimic diagram is copied from a standard CAD drawing provided by the client and the finished unit is supplied pre-wired and ready to power-up.

Applications / Limitations

The 100 Way Network Mimic Controller is a stand-alone unit with/without its own EN54-4 power supply and charger. Each output on the card is fully programmable using a PC programming suite.

Features

• 100 programmable LED driver outputs for energising and providing LED indication
• Expandable to 200 by installation of an expansion card
• Supports the connectivity of 10 Way Relay Output Card
• Large full colour graphical indication for site maps, building layouts or simply zonal indication.
• Can be located remotely by simply adding the type of mimic interface onto the Ad-Net/Ad-NeT+ Network
• Supplementary graphical indication
• Zonal or fully programmable LED option
• Fully networkable
• Full colour mimic option
• 3-year warranty as standard
